Ovehung Horisontal Pumps OH2

Fuglesangs can deliver a wide range of API 610 OH2 pumps in high quality.
The manufacturers OH2 product range complies also with different industrial standards such as API, ANSI, ISO and the hydraulic institute.
We have many references on this pump type as big boiler feed water pumps, and other demanding industrial use. Several references are available in the North Sea.
NORSOK approved materials are available.

Termomeccanica Pompe AP pumps are single stage, single suction radial impeller, end/top centrifigual pumps for heavy duty services, especially in oil & gas processing. The back pull-out arrangement allows for easy maintenance while the center-line assembly, large diameter shaft, and very stiff bearing casing assure proper alignment of the rotating parts during the most critical conditions. The seal chamber is according to API 682 for any mechanical seal configuration and API 610 for the seal flushing plan.

The all-around Gabbioneta R range process pumps provide superior efficiency for more than 100 different hydraulic configurations suitable for heavy-duty use. The R Range Gabbioneta Pumps® are overhung, horizontal radially split, centerline supported, heavy-duty process pumps, designed in a back pull-out configuration for easy maintenance, and centerline feet mounted for high temperature stability.
Coverage includes more than 100 different hydraulics, for optimum efficiency over a wide operating range. The shaft flexibility index is in full compliance with API 610 Annex K, and the twin volute configuration minimizes radial loads.


Technical data

Termomeccania Type AP
Flow up to 4000 m3/h
Head up to 400 meter
Operating temperature from -100 to +450 degrees celsius
Standard execution 100 bar


Gabbioneta Type R
Flow up to 2500 m3/h
Head up to 380 m
Operating temperature from -100 to +450 degrees celsius
Standard execution 40 bar, spesial execution up to 210 bar
RPM up to 3600
