Heavy-Duty Execution

Milton Roy ROBIN top-entry and bottom-entry agitators are custom-made and perfectly attuned to meet the specific characteristics of complex processes in extreme conditions.

Manufactured to ATEX certification standards, our expert industrial mixing engineers will work with you to understand the processes and constraints to design a ROBIN agitator specific to your application requirements.  By using computational fluid dynamics (CFD) tools, your ROBIN agitator will be designed to ensure maximum results and long-term financial benefits.

You’ll benefit from a worldwide knowledge and financial base of high-value projects.

Model A5

For use in an open tank at atmospheric pressure.

• Rotation speed: 10 to 500 rpm
• Rated power: about 0.55 to 500 kW
• Impeller diameter: 0.20 to 6 m
• Impeller type: all kind
• Construction material: all machinable metallic material
• Pressure use: atmospheric pressure
• Temperature up to 500°C
• Pressure with vaccum at 300 gauge bars
• Viscosity can be covered to the extreme

Model B5

For use when a simple tightness is required to avoid contact between the product and the atmosphere (mixing under few mbars of pressure or vacuum or when the product is dangerous or must be kept under inert atmosphere)

• Rated power: about 0.55 to 37 kW
• Rotation speed: 500 to 10 rpm
• Impeller diameter: 0.20 to 6m
• Impeller type: all kind
• Construction material: machinable metallic material
• Pressure use: few mbar difference with the atmospheric

Model E5

For use in mixing at atmospheric pressure in open tanks

• Rated power: about 0.75 to 250 kW
• Rotation speed: 500 to 10 rpm
• Impeller diameter: 0.50 to 6m
• Impeller type: all kind
• Construction material: all machinable metallic material
• Pressure use: few mbar difference of the atmospheric pressure

Model F5

For use in all operations processed under pressure or vacuum, or mixing dangerous substances.

• Rated power: about 0.75 to 250 kW
• Rotation speed: 500 to 10 rpm
• Impeller diameter: 0.25 to 6m
• Impeller type: all kind
• Construction material: all machinable metallic material
• Pressure use: full vacuum to approx. 75 Bg (250 Bg with magnetic drive)

Milton Roy Mixing has developed and adapted agitators to respond to major portions of chemical industry operations.

• Hydrometallurgy. Hydrometallurgy is a chemical process to facilitate metal extraction including recovery of iron mineral, aluminum, zinc, copper, and sterilization of special metals by biochemical treatment.  This process requires a large liquid tank capacity in order to obtain the expected chemical reaction. Agitators are an essential device and our Robin agitators can be adapted based upon the desired application such as liquid holding suspension, homogenization, gas dispersion and heat transfer.
• Fertilizers. Phosphoric acid is a fertilizer which is primarily used in agriculture. Its production is the result of mixing between natural phosphate and sulfuric acid.  This complex process requires an agitator for homogenization; so that the sulfuric acid perfectly reacts with the phosphate in the whole tank.  Milton Roy Mixing agitators can be tailored to provide optimal mixing based up the acidity and viscosity levels, and corrosion and abrasiveness of the fluids.  Our Robin mixers are resistant to the high temperatures required to melt sulfuric acid and the impellers ensure proper diffusion through the entire tank for a perfect homogenized solution.
• Mineralurgy. The processing of natural and synthetic mineral materials requires the storage of calcium carbonate particles to be held in suspension. The complexity of the process lies in the concentration of dry substance which makes the rheological behavior singular; the fluid behaves in a similar way to a pseudoplastic or a Bingham fluid, and in these cases, the fluid will likely need a storage area of 500m3, which represents a significant challenge. Milton Roy Mixing’s agitators are designed with high-diameter axial flow impellers that provide agitation throughout the entire tank.  In addition, the agitator can operate at a low speed to obtain a shear that masters the fluid flow.
