Arcos S-160
Double-acting hydraulic cylinder
Main benefits
- For medium-heavy use + heavy mobile use
- Working pressure 20/30MPa or 16/25 Mpa for acid-proff cylinders
- 6 mounting possibilities
- ISO 6020-1
- Available as standard in construction steel SS 2172 and acid resistant steel SS 2343
- ACCESS TO THE ONLINE CONFIGURATOR: ARCOS
DATA SHEET QUOTE
Product description
The S-160 double-acting hydraulic cylinder is designed by Arcos Hydraulik for medium-heavy industrial use and heavy mobile use. This hydraulic cylinder is made for heavy duty, easy maintenance with a long service life. Its users will also appreciate that there is no metallic contact between the moving parts.
In close co-operation with Fuglesangs, Arcos hydraulik offers a wide range of high quality hydraulics solutions, based on the customers wishes with optimal capacities and easy maintenance at an affordable cost.
This double-acting hydraulic cylinder is built in two different steel qualities; SS 2172 and acid-proof steel, SS 2343. Available as standard in eight dimensions, from Ø 40 to 200 mm, this hydraulic cylinder can be used in many applications.
For a better protection from corrosion, we can cover the cylinder with chemical nickel which will protect this double-acting hydraulic cylinder against acidity from pH 4 and upwards, but not from oxidising acids.
Do not hesitate to contact us if you have any question.
